| Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
| Tensile Strength | ISO 527 | 50mm/min | 54.8 | 37.5±4 | 12.3±2 | MPa |
| Elongation at Break | ISO 527 | 50mm/min | 5.7 | 3.6±1 | 1.1±0.2 | % |
| Tensile Modulus | ISO 527 | 50mm/min | 2515.7 | 2469±100 | 2142.7±100 | MPa |
| Flexural Strength | ISO 178 | 2mm/min | 78.4 | 58.9±4 | 19.4±2 | MPa |
| Flexural Modulus | ISO 178 | 2mm/min | 3766.7 | 2876.7±100 | 2082.5±100 | MPa |
| Charpy Impact Strength | ISO 179 | 23℃ | 59.3 | 23.1±2 | 2.6±1 | KJ/㎡ |
| Izod Impact Strength | ISO 180 | 23℃ | 52.8 | 18.4±2 | 2.2±1 | KJ/㎡ |
| Property | Testing Method | Testing Condition | Typical Value | Unit |
| Density | ISO 1183 | Immersion | 1.32 | g/cm3 |
| Melt Flow index(MFR) | ISO 1133 | 210℃/2.16kg | 2-7 | g/10 min |
| Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing Typical Value | Unit |
| Moisture Absorption | ISO 62 | 50%RH*23℃ | 0.4 | 0.42 | % |
| Property | Testing Result |
| Weak Acid Resistance | Not Resistant |
| Strong Acid Resistance | Not Resistant |
| Weak Base Resistance | Not Resistant |
| Strong Base Resistance | Not Resistant |
| Organic Solution Resistance | Not Resistant |
| Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
| Glass Transition Temperature | DSC | 10℃/min | 65.4 | ℃ | ||
| Crystallization temperature | DSC | 10℃/min | 95.4 | ℃ | ||
| Melting Point | DSC | 10℃/min | 150 | ℃ | ||
| Distortion Temperature | TGA | 20℃/min | N/A | ℃ | ||
| Heat Distortion Temperature | ISO 75 | 0.45MPa | 57 | 55.5 | 56.9 | ℃ |
| Heat Distortion Temperature | ISO 75 | 1.8MPa | 55.9 | 55 | 53.8 | ℃ |
| Vicat Softening Temperature | ISO 306 | 50℃/10N | 62.8 | 61.1 | 61.8 | ℃ |
| Printing Temperature | 210-230(℃) |
| Bed Temperature | 50-60(℃) |
| Wall Layers | 2 Layers |
| Top and Bottom Layers | 4 Layers |
| Infill | 100% |
| Ambient Temperature | 25℃ |
| Cooling Fan | 0-10% |
| Printing Speed | 30-50 (mm/s) |
| Nozzle Diameter | 0.4 mm |
