| Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
| Tensile Strength | ISO 527 | 50mm/min | 61.9 | 45.5±4 | 19.4±2 | MPa |
| Elongation at Break | ISO 527 | 50mm/min | 4.6 | 5.4±1 | 1.2±0.2 | % |
| Tensile Modulus | ISO 527 | 50mm/min | 2338.2 | 2055.1±100 | 1952.2±100 | MPa |
| Flexural Strength | ISO 178 | 2mm/min | 84.6 | 68.9±4 | 23.2±2 | MPa |
| Flexural Modulus | ISO 178 | 2mm/min | 2943.3 | 2647.5±100 | 2507.5±100 | MPa |
| Charpy Impact Strength | ISO 179 | 23℃ | 28.1 | 18.1±2 | 3.8±1 | KJ/㎡ |
| Izod Impact Strength | ISO 180 | 23℃ | 19 | 13.4±2 | 4.1±1 | KJ/㎡ |
| Property | Testing Method | Testing Condition | Typical Value | Unit |
| Density | ISO 1183 | Immersion | 1.25 | g/cm3 |
| Melt Flow index(MFR) | ISO 1133 | 210℃/2.16kg | 10-20 | g/10 min |
| Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing Typical Value | Unit |
| Moisture Absorption | ISO 62 | 50%RH*23℃ | 0.5 | 0.6 | % |
| Property | Testing Result |
| Weak Acid Resistance | Not Resistant |
| Strong Acid Resistance | Not Resistant |
| Weak Base Resistance | Not Resistant |
| Strong Base Resistance | Not Resistant |
| Organic Solution Resistance | Not Resistant |
| Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
| Glass Transition Temperature | DSC | 10℃/min | 65.7 | ℃ | ||
| Melting Point | DSC | 10℃/min | 163 | ℃ | ||
| Decomposition Temperature | TGA | 20℃/min | N/A | ℃ | ||
| Heat Distortion Temperature | ISO 75 | 0.45MPa | 58.6 | 57.5 | 58.6 | ℃ |
| Heat Distortion Temperature | ISO 75 | 1.8MPa | 56 | 55.7 | 52.4 | ℃ |
| Vicat Softening Temperature | ISO 306 | 50℃/10N | 67.2 | 65.4 | 62.2 | ℃ |
| Printing Temperature | 220-230(℃) |
| Bed Temperature | 50-60(℃) |
| Wall Layers | 2 Layers |
| Top and Bottom Layers | 4 Layers |
| Infill | 100% |
| Ambient Temperature | 25℃ |
| Cooling Fan | 0-10% |
| Printing Speed | 30-50(mm/s) |
| Nozzle Diameter | 0.4 mm |
